146473-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
RoHS Compliant COMMERCIAL UL CSA RECTANGULAR Spacer Connector UL94V-0 -125C 3A 0.092inch
PDF
/
Inventory: 4276
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Gold
Mount Through Hole
Contact Shape Square
Housing Material Thermoplastic
Technical
Packaging Bulk
JESD-609 Code e4
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Header, Pin, Plug
Max Operating Temperature -125°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Additional Feature AMPMODU
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Number Of PCB Rows 1
Number of Contacts 5
PCB Contact Pattern RECTANGULAR
Mating Information NO
Body Breadth 0.092 inch
Contact Gender MALE
UL Flammability Code 94V-0
Lead Length 28.7mm
Body Depth 0.47 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Compliant
Contact Pattern RECTANGULAR
Mating Post Length 8.38mm
Dimensions
Length 28.702mm
Length - Tail 8.382mm
Stack Height 11.94mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
