ZW-20-10-S-S-515-150
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 20 POS 2.54mm Solder ST Thru-Hole Bulk
PDF
/
Inventory: 1765
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mounting Type BOARD
Housing Material Polyester
Technical
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Number of Rows 1
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 2.54mm
Number of Contacts 20
UL Flammability Code 94V-0
Housing Color Black
Dimensions
Length 50.8mm
Compliance
RoHS Status ROHS3 Compliant
