TW-33-06-L-D-445-SM-A

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Stacker
PDF
/
Inventory: 2184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 66
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, TW
Published 2011
Packaging Tube
Row Spacing 0.079 (2.00mm)
Contact Finish - Post (Mating) Gold
Lead Length 15.4mm
Depth 6.54mm
Orientation Straight
Total Number of Contacts 66
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO

Physical

Housing Material Polymer
Number of Pins 33
Mounting Type Surface Mount
Contact Material Bronze

Supply Chain

Factory Lead Time 3 Weeks

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.160 4.064mm
Length - Overall Pin 0.605 15.367mm
Length - Stack Height 0.445 11.303mm
Length 66mm
