TW-32-07-G-T-425-135

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Board Spacer
PDF
/
Inventory: 6834
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 2 Weeks

Physical

Mounting Type BOARD
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Style STRAIGHT

Technical

JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Rows 3
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Total Number of Contacts 96
Terminal Pitch 2.0066mm
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 2.52 inch
Number Of PCB Rows 3
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 125°C
Body Breadth 0.237 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.425 inch
Rated Current (Signal) 5.2A
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.079 inch
Termination Type SOLDER
PCB Contact Row Spacing 2.0066 mm
Contact Finish Termination Gold (Au) - with Nickel (Ni) barrier
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.079 inch
Insulator Color BLACK

Dimensions

Plating Thickness 20μin
Length - Termination 0.135 inch

Compliance

RoHS Status ROHS3 Compliant
