TW-28-03-L-Q-250-080
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 112 POS 2mm Solder ST Thru-Hole
PDF
/
Inventory: 8388
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mounting Type BOARD
Number of Pins 28
Housing Material Polymer
Technical
Published 2016
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Number of Rows 4
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Orientation Straight
Depth 8mm
Number of Contacts 112
Housing Color Black
Lead Length 13.6mm
Max Current Rating 3A
Dimensions
Length 56mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
