TW-10-12-L-D-500-100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 20 POS 2mm Solder ST Thru-Hole
PDF
/
Inventory: 3681
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mounting Type BOARD
Number of Pins 10
Housing Material Polymer
Technical
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2mm
Total Number of Contacts 20
Orientation Straight
Depth 4mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Black
Lead Length 28.2mm
Max Current Rating 3A
Dimensions
Length 20mm
Compliance
RoHS Status ROHS3 Compliant
