TW-10-05-S-D-155-140
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 6869
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 30μin
Technical
Mating Contact Row Spacing 0.079 inch
Contact Pattern RECTANGULAR
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Body Breadth 0.155 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Number of Conductors ONE
Total Number of Contacts 20
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 2
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2016
Physical
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mount Through Hole
Contact Plating Gold
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 2 Weeks
