TW-09-05-G-D-389-062
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 18 POS 2mm Solder ST Thru-Hole
PDF
/
Inventory: 8527
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Mating Contact Row Spacing 0.079 inch
Contact Pattern RECTANGULAR
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Body Breadth 0.155 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 18
Number Of PCB Rows 2
Reliability COMMERCIAL
Number of Conductors ONE
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 2
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2016
Packaging Bulk
Physical
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 2 Weeks
