MW-50-03-G-D-200-110
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 1491
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.110 2.794mm
Length - Overall Pin 0.310 7.874mm
Length - Stack Height 0.200 5.080mm
Technical
Row Spacing 0.039 (1.00mm)
Contact Finish - Post (Mating) Gold
Contact Gender MALE
Total Number of Contacts 100
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black, Natural
Number of Positions 100
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Flex Stack, MW
Packaging Tube
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 3 Weeks
