MW-40-03-G-D-120-072

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Stacker
PDF
/
Inventory: 1768
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.072 1.829mm
Length - Overall Pin 0.192 4.877mm
Length - Stack Height 0.120 3.048mm

Technical

Row Spacing 0.039 (1.00mm)
Contact Finish - Post (Mating) Gold
Contact Gender MALE
Total Number of Contacts 80
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Number of Positions 80
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Series Flex Stack, MW
Packaging Tube

Physical

Mounting Type Surface Mount

Supply Chain

Factory Lead Time 3 Weeks
