MW-40-03-F-D-108-202

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Conn Board Stacker HDR 80 POS 1mm Solder ST SMD
PDF
/
Inventory: 3711
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount

Technical

Packaging Tube
Series Flex Stack, MW
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 80
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Total Number of Contacts 80
Contact Finish - Post (Mating) Gold
Row Spacing 0.039 (1.00mm)

Dimensions

Length - Stack Height 0.108 2.743mm
Length - Overall Pin 0.310 7.874mm
Length - Post (Mating) 0.202 5.131mm
Contact Finish Thickness - Post (Mating) 3.00μin 0.076μm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
