MW-25-03-G-D-215-070
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 5102
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Connector Type BOARD STACKING CONNECTOR
Number of Positions 50
Color Black, Natural
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Total Number of Contacts 50
Contact Finish - Post (Mating) Gold
Row Spacing 0.039 (1.00mm)
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, MW
Packaging Tube
Dimensions
Length - Stack Height 0.215 5.461mm
Length - Overall Pin 0.285 7.239mm
Length - Post (Mating) 0.070 1.778mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Surface Mount
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
