MW-25-03-G-D-185-100-P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 50 POS 1mm Solder ST SMD Bulk
PDF
/
Inventory: 954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Option 1 LOCKING
Technical
Packaging Tube
Series Flex Stack, MW
JESD-609 Code e4
Part Status Active
Termination Solder
Connector Type BOARD CONNECTOR
Number of Positions 50
Color Black, Natural
Number of Rows 2
Gender Male
Subcategory Headers and Edge Type Connectors
Pitch 0.039 1.00mm
Total Number of Contacts 50
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.984 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Min) -55°C
Body Depth 0.185 inch
Contact Finish - Post (Mating) Gold
Contact Style SQ PIN-SKT
Row Spacing 0.039 (1.00mm)
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Dimensions
Plating Thickness 10μin
Length - Stack Height 0.185 4.699mm
Length - Overall Pin 0.285 7.239mm
Length - Post (Mating) 0.100 2.540mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
