MW-20-03-G-D-135-065-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 40 POS 1mm Solder ST SMD Tube
PDF
/
Inventory: 6900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.065 1.651mm
Length - Overall Pin 0.200 5.080mm
Length - Stack Height 0.135 3.429mm
Technical
Row Spacing 0.039 (1.00mm)
Contact Finish - Post (Mating) Gold
Total Number of Contacts 40
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black, Natural
Number of Positions 40
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, MW
Packaging Tube
Physical
Mounting Type Surface Mount
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
