MW-20-03-G-D-110-080
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 40 POS 1mm Solder ST SMD Tube
PDF
/
Inventory: 2349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Technical
Packaging Tube
Series Flex Stack, MW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 40
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Total Number of Contacts 40
Contact Finish - Post (Mating) Gold
Row Spacing 0.039 (1.00mm)
Dimensions
Length - Stack Height 0.110 2.794mm
Length - Overall Pin 0.190 4.826mm
Length - Post (Mating) 0.080 2.032mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
