MW-07-03-H-D-245-065-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 6077
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
Packaging Tape & Reel (TR)
Series Flex Stack, MW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Positions 14
Color Black, Natural
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Pitch 0.039 1.00mm
Total Number of Contacts 14
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Operating Temperature (Min) -55°C
Contact Finish - Post (Mating) Gold
Contact Style SQ PIN-SKT
Row Spacing 0.039 (1.00mm)
Contact Pattern RECTANGULAR
Dimensions
Plating Thickness 30μin
Length - Stack Height 0.245 6.223mm
Length - Overall Pin 0.310 7.874mm
Length - Post (Mating) 0.065 1.651mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Compliance
RoHS Status ROHS3 Compliant
