MW-07-03-H-D-215-080-P-TR

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Stacker
PDF
/
Inventory: 6318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Post (Mating) 0.080 2.032mm
Length - Overall Pin 0.295 7.493mm
Length - Stack Height 0.215 5.461mm

Technical

Row Spacing 0.039 (1.00mm)
Contact Finish - Post (Mating) Gold
Contact Gender MALE
Total Number of Contacts 14
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black, Natural
Number of Positions 14
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Flex Stack, MW
Packaging Tape & Reel (TR)

Physical

Mounting Type Surface Mount
