MW-06-03-G-D-210-075-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 12 POS 1mm Solder ST SMD T/R
PDF
/
Inventory: 5160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Technical
Packaging Tape & Reel (TR)
Series Flex Stack, MW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 12
Color Black, Natural
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Total Number of Contacts 12
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish - Post (Mating) Gold
Row Spacing 0.039 (1.00mm)
Dimensions
Length - Stack Height 0.210 5.334mm
Length - Overall Pin 0.285 7.239mm
Length - Post (Mating) 0.075 1.905mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
