HW-50-19-G-D-866-110
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 7722
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
UL Flammability Code 94V-0
Contact Gender MALE
Total Number of Contacts 100
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Number of Positions 100
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Flex Stack, HW
Packaging Bulk
Dimensions
Length - Stack Height 0.866 21.996mm
Length - Overall Pin 1.330 33.782mm
Length - Post (Mating) 0.354 8.992mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.110 2.800mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Through Hole
Supply Chain
Factory Lead Time 3 Weeks
