HW-23-11-S-S-575-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 3844
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Post (Mating) 0.290 7.366mm
Length - Overall Pin 0.865 21.971mm
Length - Stack Height 0.575 14.605mm
Technical
Contact Finish - Post (Mating) Gold
Total Number of Contacts 23
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 1
Color Black
Number of Positions 23
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, HW
Packaging Bulk
Physical
Mounting Type Surface Mount
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 3 Weeks
