HW-14-11-G-D-615-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 28 POS 2.54mm Solder ST SMD Tube
PDF
/
Inventory: 3879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.250 6.350mm
Length - Overall Pin 0.865 21.971mm
Length - Stack Height 0.615 15.621mm
Length 21.971mm
Technical
Max Current Rating 3A
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Depth 7.37mm
Orientation Straight
Total Number of Contacts 28
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 28
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, HW
Published 2000
Packaging Bulk
Physical
Housing Material Polymer
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Bronze
Supply Chain
Factory Lead Time 6 Weeks
