HW-07-08-L-S-375-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 4752
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.090 2.286mm
Length - Overall Pin 0.465 11.811mm
Length - Stack Height 0.375 9.525mm
Technical
Contact Finish - Post (Mating) Gold
Total Number of Contacts 7
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 1
Color Black
Number of Positions 7
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, HW
Packaging Bulk
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 3 Weeks
