HW-05-15-T-S-435-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 5POS 0.1 STACK SMD TIN
PDF
/
Inventory: 9822
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Technical
Packaging Tube
Series Flex Stack, HW
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 5
Color Black
Number of Rows 1
Additional Feature STAGGERED CONFIGURATION
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 5
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Tin
Dimensions
Length - Stack Height 0.435 11.049mm
Length - Overall Pin 0.565 14.351mm
Length - Post (Mating) 0.130 3.302mm
Compliance
RoHS Status ROHS3 Compliant
