HW-05-12-L-D-395-SM

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Conn Board Stacker HDR 10 POS 2.54mm Solder ST SMD
PDF
/
Inventory: 5485
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount

Technical

Packaging Bulk
Series Flex Stack, HW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 10
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 10
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)

Dimensions

Length - Stack Height 0.395 10.033mm
Length - Overall Pin 0.965 24.511mm
Length - Post (Mating) 0.570 14.478mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
