HW-04-10-L-S-375-312
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 4 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 8484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Mounting Type Through Hole
Housing Material Polymer
Technical
Packaging Bulk
Published 2016
Series Flex Stack, HW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 4
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 4
Orientation Straight
Depth 2.54mm
Housing Color Natural
Contact Finish - Post (Mating) Gold
Dimensions
Length 10.16mm
Length - Stack Height 0.375 9.525mm
Length - Overall Pin 0.830 21.082mm
Length - Post (Mating) 0.143 3.632mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.312 7.925mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
