HW-01-08-T-S-242-079
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 7368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Technical
Packaging Bulk
Series Flex Stack, HW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 1
Color Black
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 1
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Tin
Dimensions
Length - Stack Height 0.242 6.147mm
Length - Overall Pin 0.530 13.462mm
Length - Post (Mating) 0.209 5.309mm
Length - Tail 0.079 2.007mm
Compliance
RoHS Status ROHS3 Compliant
