HDWM-40-54-L-D-250-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 80 POS 1.27mm Solder ST SMD Bulk
PDF
/
Inventory: 7081
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Surface Mount
Technical
Packaging Bulk
Series Flex Stack, HDWM
JESD-609 Code e3
Part Status Active
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 80
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 80
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Dimensions
Length - Stack Height 0.250 6.350mm
Length - Overall Pin 0.535 13.589mm
Length - Post (Mating) 0.285 7.239mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
