HDWM-15-61-G-D-661

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description CONN HDR 30POS 0.05 STACK T/H
PDF
/
Inventory: 5405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Dimensions

Length - Overall Pin 1.050 26.670mm
Length - Stack Height 0.661 16.789mm
Length - Tail 0.120 3.048mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.269 6.833mm

Technical

Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
Pitch 0.050 1.27mm
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Number of Positions 30
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e4
Series Flex Stack, HDWM
Packaging Bulk

Physical

Mounting Type Through Hole

Supply Chain

Factory Lead Time 3 Weeks

Compliance

RoHS Status ROHS3 Compliant
