HDWM-12-59-G-D-520-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 5160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.465 11.811mm
Length - Overall Pin 0.985 25.019mm
Length - Stack Height 0.520 13.208mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
UL Flammability Code 94V-0
Total Number of Contacts 24
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Number of Positions 24
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
JESD-609 Code e4
Series Flex Stack, HDWM
Published 2011
Packaging Bulk
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 3 Weeks
