HDWM-05-01-L-S-275
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 4522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Active
Series Flex Stack, HDWM
Packaging Bulk
Contact Finish - Post (Mating) Gold
Pitch 0.050 1.27mm
Number of Rows 1
Color Black
Number of Positions 5
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Physical
Mounting Type Through Hole
Supply Chain
Factory Lead Time 3 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.120 3.048mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.055 1.397mm
Length - Overall Pin 0.450 11.430mm
Length - Stack Height 0.275 6.985mm
