FW-50-03-G-D-294-080
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
LOW PROFILE Rectangular Connector Stacker
PDF
/
Inventory: 4024
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.080 2.032mm
Length - Overall Pin 0.374 9.500mm
Length - Stack Height 0.294 7.468mm
Technical
Row Spacing 0.050 (1.27mm)
Contact Finish - Post (Mating) Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Total Number of Contacts 100
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Gender Male
Number of Rows 2
Color Black
Number of Positions 100
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, FW
Packaging Tube
Physical
Mounting Type Surface Mount
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
