FW-30-03-L-D-285-065

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Board Spacer
PDF
/
Inventory: 2279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 60
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Gold
Row Spacing 0.050 (1.27mm)
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Number of Positions 60
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Part Status Active
Series Flex Stack, FW
Packaging Bulk

Dimensions

Length - Stack Height 0.285 7.239mm
Length - Overall Pin 0.350 8.890mm
Length - Post (Mating) 0.065 1.651mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm

Compliance

RoHS Status ROHS3 Compliant

Physical

Mounting Type Surface Mount

Supply Chain

Factory Lead Time 3 Weeks
