FW-07-03-F-D-270-110
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 3166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Surface Mount
Technical
Packaging Bulk
Series Flex Stack, FW
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 14
Color Black
Number of Rows 2
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 14
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Gold
Row Spacing 0.050 (1.27mm)
Dimensions
Length - Stack Height 0.270 6.858mm
Length - Overall Pin 0.380 9.652mm
Length - Post (Mating) 0.110 2.794mm
Contact Finish Thickness - Post (Mating) 3.00μin 0.076μm
Compliance
RoHS Status ROHS3 Compliant
