FW-04-03-G-D-265-120-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 8 POS 1.27mm Solder ST SMD
PDF
/
Inventory: 5299
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Surface Mount
Technical
Packaging Bulk
Series Flex Stack, FW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 8
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 8
Contact Finish - Post (Mating) Gold
Row Spacing 0.050 (1.27mm)
Dimensions
Length - Stack Height 0.265 6.731mm
Length - Overall Pin 0.385 9.779mm
Length - Post (Mating) 0.120 3.048mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
