FW-02-01-G-D-070-065
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 6122
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.045 1.143mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.065 1.651mm
Length - Overall Pin 0.180 4.572mm
Length - Stack Height 0.070 1.778mm
Plating Thickness 10μin
Technical
Contact Pattern RECTANGULAR
Row Spacing 0.050 (1.27mm)
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
Body Depth 0.07 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.135 inch
Mating Information NO
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.1 inch
Reliability COMMERCIAL
Number of Conductors ONE
Total Number of Contacts 4
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Black
Number of Positions 4
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, FW
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Type Through Hole
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
