EW-16-12-L-D-500-001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 32 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 9678
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Bulk
Published 2016
Series Flex Stack, EW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Number of Positions 32
Color Black
Number of Rows 2
Gender Male
Pitch 0.100 2.54mm
Number of Contacts 32
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Dimensions
Length - Stack Height 0.500 12.700mm
Length - Overall Pin 1.030 26.162mm
Length - Post (Mating) 0.200 5.080mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.330 8.382mm
Compliance
RoHS Status ROHS3 Compliant
