EW-10-12-G-D-438
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 20POS 0.1 STACK T/H
PDF
/
Inventory: 6757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Technical
Packaging Bulk
Series Flex Stack, EW
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Positions 20
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 20
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Dimensions
Length - Stack Height 0.438 11.125mm
Length - Overall Pin 1.030 26.162mm
Length - Post (Mating) 0.262 6.655mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.330 8.382mm
Compliance
RoHS Status ROHS3 Compliant
