DWM-40-51-SM-D-200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 80 POS 1.27mm Solder ST Thru-Hole
PDF
/
Inventory: 7937
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Mounting Type Through Hole
Housing Material Polymer
Technical
Packaging Bulk
Published 2011
Series Flex Stack, DWM
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 80
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 80
Orientation Straight
Depth 4.98mm
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Max Current Rating 1A
Dimensions
Length 50.8mm
Length - Stack Height 0.200 5.080mm
Length - Overall Pin 0.410 10.414mm
Length - Post (Mating) 0.090 2.286mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Tail 0.120 3.048mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
