DWM-22-54-S-D-250
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 44 POS 1.27mm Solder ST Thru-Hole
PDF
/
Inventory: 2650
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.120 3.048mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Post (Mating) 0.185 4.699mm
Length - Overall Pin 0.555 14.097mm
Length - Stack Height 0.250 6.350mm
Plating Thickness 30μin
Technical
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 600VAC V
Body/Shell Style RECEPTACLE
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
Rated Current (Signal) 1A
Operating Temperature (Min) -65°C
Body Breadth 0.196 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 1.1 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 44
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Male
Number of Rows 2
Color Black
Number of Positions 44
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DWM
Published 2011
Packaging Bulk
Physical
Insulation Material NYLON
Mounting Type Through Hole
Mount Through Hole
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
