DWM-01-55-L-D-250
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 1711
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
Packaging Bulk
Series Flex Stack, DWM
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 2
Color Black
Number of Rows 2
Gender Male
Contact Pattern RECTANGULAR
Row Spacing 0.100 (2.54mm)
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
Operating Temperature (Min) -55°C
Body Breadth 0.196 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.05 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Total Number of Contacts 2
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Dimensions
Length - Overall Pin 0.610 15.494mm
Length - Post (Mating) 0.240 6.096mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.120 3.048mm
Length - Stack Height 0.250 6.350mm
Plating Thickness 10μin
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
