DW-40-15-G-D-214-LL-001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 2262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length - Tail 0.110 2.794mm
Length - Termination 0.11 inch
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.306 7.772mm
Length - Overall Pin 0.630 16.002mm
Length - Stack Height 0.214 5.436mm
Plating Thickness 10μin
Technical
Contact Pattern RECTANGULAR
Row Spacing 0.100 (2.54mm)
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
Operating Temperature (Min) -55°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 4 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Total Number of Contacts 80
Pitch 0.100 2.54mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Male
Number of Rows 2
Color Black
Number of Positions 80
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Flex Stack, DW
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYESTER
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 3 Weeks
