DW-25-16-H-D-200

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Stacker
PDF
/
Inventory: 8399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 50
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Number of Positions 50
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Flex Stack, DW
Packaging Bulk

Dimensions

Length - Stack Height 0.200 5.080mm
Length - Overall Pin 0.445 11.303mm
Length - Post (Mating) 0.135 3.429mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Tail 0.110 2.794mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Mounting Type Through Hole
Mount Through Hole
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 3 Weeks
