DW-22-13-F-S-935
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 4934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Technical
Packaging Bulk
Series Flex Stack, DW
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 22
Color Black
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 32
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
UL Flammability Code 94V-0
Contact Finish - Post (Mating) Gold
Dimensions
Length - Stack Height 0.935 23.749mm
Length - Overall Pin 1.230 31.242mm
Length - Post (Mating) 0.185 4.699mm
Contact Finish Thickness - Post (Mating) 3.00μin 0.076μm
Length - Tail 0.110 2.794mm
Compliance
RoHS Status ROHS3 Compliant
