DW-20-08-T-S-315
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 20 POS 2.54mm Solder ST Thru-Hole
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.799283
≥1 USD $1.799283
≥10 USD $1.697439
≥100 USD $1.601353
≥500 USD $1.510708
≥1000 USD $1.425203
Inventory: 8487
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.110 2.794mm
Length - Post (Mating) 0.105 2.667mm
Length - Overall Pin 0.530 13.462mm
Length - Stack Height 0.315 8.000mm
Technical
Contact Finish - Post (Mating) Tin
Total Number of Contacts 20
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 1
Color Black
Number of Positions 20
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DW
Published 2016
Packaging Bulk
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 3 Weeks
