DW-16-20-L-D-450
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 32 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 3586
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Termination Solder
Number of Positions 32
Color Black
Number of Rows 2
Gender Male
Pitch 0.100 2.54mm
Number of Contacts 32
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Flex Stack, DW
Packaging Bulk
Dimensions
Length - Stack Height 0.450 11.430mm
Length - Overall Pin 1.130 28.702mm
Length - Post (Mating) 0.570 14.478mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.110 2.794mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 3 Weeks
