DW-12-13-S-D-900
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 24 POS 2.54mm Solder ST Thru-Hole
PDF
/
Buying Options
Total Price: USD $6.58
Unit Price: USD $6.582091
≥1 USD $6.582091
≥10 USD $6.209524
≥100 USD $5.85804
≥500 USD $5.526445
≥1000 USD $5.21363
Inventory: 3465
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length - Tail 0.110 2.794mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Post (Mating) 0.220 5.588mm
Length - Overall Pin 1.230 31.242mm
Length - Stack Height 0.900 22.860mm
Length 30.48mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
UL Flammability Code 94V-0
Depth 5.08mm
Orientation Straight
Total Number of Contacts 24
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 24
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DW
Published 2012
Packaging Bulk
Physical
Housing Material Polyester
Mounting Type Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
