DW-12-12-G-S-669
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 12POS 0.1 STACK T/H
PDF
/
Inventory: 5888
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Technical
Packaging Bulk
Series Flex Stack, DW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Positions 12
Color Black
Number of Rows 1
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 12
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
Contact Finish - Post (Mating) Gold
Dimensions
Length - Stack Height 0.669 16.993mm
Length - Overall Pin 1.030 26.162mm
Length - Post (Mating) 0.251 6.375mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.110 2.794mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
