DW-10-10-L-D-450-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 9356
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.110 2.794mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.270 6.858mm
Length - Overall Pin 0.830 21.082mm
Length - Stack Height 0.450 11.430mm
Length 25.4mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
Housing Color Black
Number of Contacts 20
Depth 5.08mm
Orientation Straight
Pitch 0.100 2.54mm
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 20
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Flex Stack, DW
Published 2011
Packaging Bulk
Physical
Housing Material Polyester
Mounting Type Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
