DW-09-10-S-S-410

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Board Spacer
PDF
/
Inventory: 6153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Positions 9
Color Black
Number of Rows 1
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 9
Contact Finish - Post (Mating) Gold
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DW
Published 2016
Packaging Bulk

Dimensions

Length - Stack Height 0.410 10.414mm
Length - Overall Pin 0.830 21.082mm
Length - Post (Mating) 0.310 7.874mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Tail 0.110 2.794mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Mounting Type Through Hole
Mount Through Hole
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 3 Weeks
