DW-06-12-T-S-600
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 6 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 2658
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length - Tail 0.110 2.794mm
Length - Post (Mating) 0.320 8.128mm
Length - Overall Pin 1.030 26.162mm
Length - Stack Height 0.600 15.240mm
Length 15.24mm
Technical
Max Current Rating 3A
Contact Finish - Post (Mating) Tin
Depth 2.54mm
Orientation Straight
Total Number of Contacts 6
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DW
Published 2014
Packaging Bulk
Physical
Housing Material Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
